Introduction

Energy Sistem™ thank you for purchasing the new Extra Battery 10000+. We hope you will
enjoy it. This portable and rechargeable battery with 10000mAh capacity is ideal to recharge
your smartphone, tablet, multimedia player or other devices wherever you go. Built-in cable and charge 2 devices at the same time. We recommend you to read this user manual in order to get the most of your device on an easily and comfortable way, enjoying all features. Find the whole ENERGY EXTRA BATTERY 10000+ user manual on the following weblink http://www.energysistem.com/guide/42005

General presentation

1 - USB cable type A-Micro USB

2 - LED battery level indicator

3 - Input: Micro USB 5V / 1000mA

4 - Output: USB 5V / 1000mA

Main features

  • Reliable, efficient and light lithium polymer battery.
  • Built-in USB cable to avoid tangles and losing the cable.
  • Intelligent circuit that allows you to charge 2 devices at the same time.
  • Ideal to charge smartphones, compatible with all market brands*.
  • Intelligent Protection System when overcharging, voltage spikes and short circuit.
  • LED charge indicator.
  • Shake the battery to monitor the battery level.
  • The battery keeps 95% charge up to 30 days.
  • Pre-charged battery for immediate use.
  • Portable and rechargeable lithium polymer battery 3.6V/10000mAh.
  • Auto Power Off in order to save battery power.
  • Input: Micro USB 5V / 1000mA; charge through standard 5V USB Host.
  • Output: USB 5V / 1000mA.

*Iphone/Ipad connectors not included.

Product content

  • 1 x Extra Battery 10000+ with built-in Micro USB type A cable.
  • 1 x User manual.

Usage instructions

Portable device charges:

Connect the built-in USB cable with the micro USB port (1) of the portable device you want to charge. Charging process will start automatically. The LED indicators will flash indicating the current capacity of battery. Once the charge is finished, disconnect the device and the Extra Battery will switch off automatically.

Extra Battery charge:

Connect the cable USB type A-Micro USB (1) with the micro USB port of your Extra Battery (3), then connect the USB type A end with a 5V charger or computer's USB port. Charging process will start automatically, LED indicator (2) will flash sequentially to indicate that the battery is charging and its level. When the charging process is finished, every LED indicator (2) will be on, indicating the battery is completely charged. Disconnect the Extra Battery and it will switch off automatically.

IMPORTANT

Shake the battery to monitor the battery level.

Charging the Extra Battery with a device connected at the same time is not recommanded, as this procedure may reduce the normal life-cycle of battery.

FAQs

Why is it impossible to recharge all devices with 10000 mAh (battery's capacity indicated)?

10000 mAh is the internal lithium battery capacity of Extra Battery 10000+. During charging process, the circuit of both Extra Battery 10000+ and the device will consume a part of power from the battery. But this part also changes depending on the kind of device charged. Therefore, the battery cannot full recharge devices with a 10000mAh battery.

Care and maintenance

  • Do not expose your Extra Battery to knocks, dust, direct sunlight or high temperatures.
  • Do not use corrsive nor abrasive cleaning products.
  • Keep your Extra Battery clean and without dust, with a soft and dry cloth, clean the device while it is off and disconnect it from the electric current.
  • Do not disassemble Extra Battery. All reparation should be done exclusively Energy Sistem Soyntec S.A qualified staff.

Warranty

Energy Sistem Soyntec SA is liable for any lack of conformity which exists at the time the goods were purchased during a period of 36 months. Batteries are excluded from the 36-month warranty, having a warranty
period of 24 months.

This warranty covers any defects in workmanship or materials. This warranty does not cover any failure of the product due to accidents, misuse or alteration made by an unauthorized person.

The special 36-months warranty is valid for the European Union. For other countries, please refer to your specific legislation

Warranty procedure

Visit the Support section at http://support.energysistem.com and select your product to view the FAQ (Frequently Asked Questions), user manuals, drivers and updates available, as the possibility to submit a query to the Technical Service or consult the warranty.

  1. You can check the availability of the user manual in your language at http://www.energysistem.com/guide/39530
  2. Alternatively, you may prefer to contact the distributor from which you purchased the product, presenting the purchase receipt or invoice.

Specifications are subject to change without notice.

Trademarks. All company, brand and product names are trademarks or registered trademarks of their respective companies.

2014 by Energy Sistem Soyntec S.A. All rights reserved.

Declaration of conformity

Manufacturer Name: Energy Sistem Soyntec S.A.
Address: Pol. Ind. Finestrat C/. Calpe, 1 - 03509 Finestrat Alicante (Spain).
Tel: 902 388 388 // Fax: 902 119 034 // NIF: A53107488

We declare under our own exclusive responsibility that the product:

Energy Sistem™ - Extra Battery 10000+

Manufacturing Country: China

Is in compliance with the essential norms and standards of the Directive 2004/i08/CE of the European Parliament and of the Council of December 15th 2004.
