Introduction

  • Thank you for trusting our company and buying the new Speaker FS3. We hope you enjoy it.
  • Stereo speaker with Bluetooth 5.0 and True Wireless Stereo technology to pair two units simultaneously and enjoy music with twice as much power.
  • Double membrane delivering enhanced bass.
  • USB/MicroSD MP3 player and audio-in.
  • Before you start using your Speaker FS3 we strongly recommend reading this manual to get used to it.


Care and maintenance

  • Do not expose your Speaker FS3 to impacts, dust, humidity or high temperatures.
  • Use neither corrosive nor abrasive cleaning products.
  • Do not disassemble the device. All repair works should be carried out exclusively by qualified staff of Energy Sistem Technology, S.A.
  • Please make sure your Speaker FS3 is off when you are not using it. Do not let it completely discharged for a long time.


Features

General features

  • Have fun with this speaker that combines style and functionality. Listen to music via Bluetooth 5.0, TWS and MP3 player.
  • True Wireless Stereo technology makes it possible to pair two speakers and get twice as much power.
  • Speaker coated with highly resistant fabric, available in bright colours.
  • Hands-free function to answer your calls wirelessly.
  • 20 W of power.
  • Play the MP3 files from your microSD cards or USB memory sticks (up to 64 GB capacity).
  • 10 hours of battery life to enjoy music from dawn to dusk.


Technical specifications

Audio

  • System: 2.0
  • Power: 20 W
  • 2 x 2.25-inch full range speakers
  • Passive radiator: two membranes
  • Frequency response: 80 Hz ~ 18 kHz
  • Signal/Noise ratio: > 60 dB

Wireless connectivity

  • Bluetooth v5.0, class II. Up to 20 m distance range
  • Compatible Bluetooth profiles: HSP / HFP / A2DP / AVRCP
  • Frequency band: 2.4 GHz (2.402 ~ 2.480 GHz).
  • Maximum output power: < 20 dBm
  • Hands-free function. Microphone sensitivity: -42 dB
  • True Wireless Stereo (TWS) technology

TWS technology compatible with

  • Speaker FS3

Audio input

  • 3.5 mm mini jack stereo audio-in (AUX)

MicroSD and USB player

  • MicroSD and USB decoder: reads MP3 and WAV files stored on external units (up to 64 GB) with FAT/ FAT32 file system.

Battery

  • Capacity: 3000 mAh
  • Type: lithium polymer
  • Battery life: up to 10 hours*
  • Charging port: USB Type-C
  • Charging time: 2 hours

Important: *The battery life depends on the selected volume level and the type of music.


Product content

  • Speaker FS3
  • USB Type-C cable
  • Quick guide
  • Strap


General overview

Imagen1

  1. On/Off/Play/Pause/Calls
  2. Volume +/Next
  3. Volume -/Back
  4. Playback mode/Voice assistant
  5. Microphone
  6. LED indicator
  7. MicroSD card slot
  8. USB port
  9. USB Type-C charging port
  10. Auxiliary audio input


Main Functions

Switching on and off the device

To switch on your Speaker FS3, press and hold On/Off/Play/Pause/Calls (1) for 2 seconds. At this point, you will hear a confirmation sound. The blue LED indicator (6) lights up.

To turn off the device, press and hold On/Off/Play/Pause/Calls (1) for 2 seconds. You will also hear a confirmation sound. At this point, the LED indicator (6) switches off.

Important: To force the device to shut down, press the hidden reset button located inside the Auxiliary audio input (10).


Playback modes

Once the Speaker FS3 is on, you can choose the playback mode you prefer. To do so, press Playback mode/Voice assistant (4) repeatedly until finding the preferred playback mode. Playback modes will appear in the following order:

Bluetooth --> microSD --> USB --> Audio-in

You will also hear the word identifying each mode.


Playback control

Select a playback mode and you will be able to control all playback functions from your Speaker FS3.

Press On/Off/Play/Pause/Calls (1) to play or pause a song.

Press Volume +/Next (2) or Volume -/Back (3) to adjust the volume level according to your preferences. You will hear a warning sound when reaching the maximum volume.

Press and hold Volume +/Next (2) or Volume -/Back (3) for 2 seconds to skip to the next or previous track.

When using a removable storage unit such as a USB stick or microSD card, you only have to press Playback mode/Voice assistant (4) twice to skip to another folder. To enable shuffle mode, press and hold the very same button for 2 seconds. You will hear a confirmation sound every time you enable/disable shuffle mode.

Important: Bear in mind that you can only manage playback from the connected music player while using the Auxiliary audio input (10).


Bluetooth

To pair your speaker with a Bluetooth device, press Playback mode/Voice assistant (4). Select Bluetooth mode. At this point, the LED indicator (6) flashes blue. You will hear a confirmation sound when the device enters search mode.

Access the Bluetooth settings on your device and search for the Speaker FS3 among the detected devices. Select it to establish the connection. The devices will be connected immediately. You will hear a sound confirming both devices are correctly paired.

Your Speaker FS3 will automatically pair with your source device when you turn the speaker on again, provided that Bluetooth is enabled on the source device.

Your Speaker FS3 turns off automatically after 5 minutes in Bluetooth mode, if not paired with any device.

The Bluetooth wireless connection range is up to 20 metres.


True Wireless Stereo (TWS)

This technology allows you to wirelessly connect a second Speaker FS3 within a maximum distance range of 20 metres to increase power and create a stereo system with separate left and right channels.

To do so, pair one speaker with your smartphone via Bluetooth first. Once you've done this, switch on the second speaker and enable Bluetooth mode.

Press and hold Playback mode/Voice assistant (4) for 2 seconds on both speakers. You will see the Bt symbol flashing quickly on both units. A few seconds later you will hear a sound to confirm both devices have been successfully synchronized.
You will hear the music through both speakers at the same time. One speaker will be assigned the left channel (L) and the other one the right channel (R).

The next time you turn on both speakers, they will pair with one another automatically.

To disable the True Wireless Stereo function, press and hold Playback mode/Voice assistant (4) for two seconds on any speaker. You will hear a confirmation sound when both units disconnect.

Skip to the next/previous track and adjust the volume from any speaker while TWS mode is enabled. If you turn up the volume on any of the speakers, you will be turning up the volume of both devices at the same time.

Note: This is only possible if Bluetooth mode is enabled. In all other playback modes (USB, microSD or AUX-in) a TWS connection is not possible.


Removable storage units (USB sticks/MicroSD cards)

The Speaker FS3 plays .mp3 and .wav files from 64 GB USB sticks or microSD cards with FAT/ FAT32 file system. Plug the microSD card into the MicroSD card slot (7) or the USB stick into the USB port (8). The speaker plays the contents automatically a few seconds after plugging the storage unit.

If you turn off the Speaker FS3 or select another playback mode, the internal memory will save the moment where you paused playback. This way, music playback will always resume from the last track you listened to.

Press On/Off/Play/Pause/Calls (1) to play or pause a song.

Press Volume +/Next (2) or Volume -/Back (3) to adjust the volume level according to your preferences. You will hear a warning sound when reaching the maximum volume.

Press and hold Volume +/Next (2) or Volume -/Back (3) for 2 seconds to skip to the next or previous track.

Press Playback mode/Voice assistant (4) twice to skip to another folder.

To enable or disable shuffle mode, press Playback mode/Voice assistant (4) for 2 seconds. You will hear a confirmation sound every time you enable/disable this mode.

The root folders and files of your removable microSD cards will be read in chronological order and the songs included in your folders in alphabetical order.

Here you have a diagram of the reading order:

Esquema


Auxiliary audio input

Your Speaker FS3 features an Auxiliary audio input (10) to connect your external devices using an audio cable with 3.5 mm mini jack plug.

Important: It is not possible to manage music playback from the speaker while using this mode. You will have to use the connected music player instead.


Call control (Hands-free function)

You can control your calls from the speaker itself. To do so, pair the Speaker FS3 with your smartphone.

When receiving a call, the song you are listening to stops and the ringing tone sounds instead. Press On/Off/Play/Pause/Calls (1) to answer the call. Press it once again to hang up.

Important: If you receive an incoming call while TWS mode is enabled, you will only hear the voice of the person who calls through the speaker connected to your smartphone.


Voice Assistant

The Speaker FS3 allows you to activate your smartphone's voice assistant. You only have to press Playback mode/Voice assistant (4) twice. This way, you will directly activate your smartphone's assistant via Bluetooth.

This function will let you ask questions and use voice commands to perform tasks naturally and easily.

You can also take a look at Google Assistant and Siri user guides, available on their manufacturers' websites.


Charging the battery

When the battery level is below 10%, you will hear a sound reminding you to charge it. To charge the battery, plug the USB Type-C end of the provided USB cable into the USB Type-C charging port (9) and the other USB end to any device with a 5 V USB port (PC, USB wall charger, car charger, etc.). The LED of the USB Type-C charging port (9) lights up red and switches off once the charging process has been completed.

The speaker has an approximate battery life of 10 hours. It depends on the selected volume and the type of music.

The charging time is approximately 2 hours.

Important:

  • Use a 5 V 2 A AC/DC power adapter.
  • Do not leave your Speaker FS3 completely discharged for a long time.


Reset

To force the device to shut down, press the hidden reset button located inside the Auxiliary audio input (10).

Note: Avoid using metallic objects when performing the reset.

Firmware update

Download the last version here


Warranty

You can check the warranty terms here:
https://www.energysistem.com/terms-warranty


Declaration of conformity

Issuer's name: Energy Sistem Technology, S.A. - CIF: A53107488
Address: C/ Calpe, 1 - 03509 Finestrat, Alicante (Spain)
Tel: +34 966 830 324

We declare under our sole and exclusive responsibility that the product:

Description: Bluetooth speaker
Brand: Energy Sistem
Model: Speaker FS3
Manufacturer: Energy Sistem Technology, S.A.
Manufacturing country: China

referred to in this declaration complies with the essential norms and standards:

EN62368-1:2014+A11:2017
EN 62479:2010
ETSI EN 301 489-1 V2.2.3 (2019-11)
EN301 489-17 V3.2.3 (2020-07)
ETSI EN 301 489-52 V1.1.0 (2016-11)
ETSI EN 300 328 V2.2.2 (2019-07)
ETSI EN 303 345 V1.1.7 (2017-03)

in conformity with the provisions of the Directive 2014/53/EU of the European Parliament and of the Council of 16th April 2014.

Finestrat, 1st September 2020

Imagen1
Miguel Ángel Aragüez García
Innovation and Technology Director
