Introduction

  • Thank you for trusting our company and buying the new Gaming Headset ESG Metal Core. We hope you enjoy the product.


Care and maintenance

  • Do not expose your Gaming Headset ESG Metal Core to impacts, dust, humidity or high temperatures.
  • Do not use neither corrosive nor abrasive cleaning products.
  • Keep the headset clean and free of dust using a soft dry cloth.
  • Do not disassemble your headphones. All repair works should be carried out exclusively by qualified staff of Energy Sistem Technology, S.A.


Features

Technical specifications

AUDIO

  • Frequency response: 20 Hz ~ 20 kHz
  • Driver diameter: 50 mm
  • SPL: 107 ± 3 dB
  • Maximum power: 30 mW
  • Closed, over-ear design
  • Type: dynamic

CABLE

  • Length: 170 cm
  • Connector: 3.5 mm jack and USB-A (LED)

MICROPHONE

  • Type: flexible microphone
  • Sensitivity: -38 dB ± 3 dB (@1 kHz)
  • Frequency range: 100 Hz ~ 10 kHz

OTHER FEATURES

  • Ear cup volume and microphone control
  • LED lighting
  • Self-adjusting headband

COMPATIBILITY

  • Windows PC
  • Mac
  • Xbox One S/X
  • PS4
  • PS5
  • Nintendo Switch
  • Mobile devices


Product content

  • Gaming Headset ESG Metal Core


General overview

  1. Volume +/ Volume
  2. On/Off switch (microphone)
  3. 3.5 mm jack plug
  4. USB connector


Main Functions

Switching on and off the device

To start using your Gaming Headset ESG Metal Core, connect the 3.5 mm jack plug (3) and the USB connector (4) to your PC or console. If your source device features two separate audio and microphone connections, we recommend using a 2 male to 1 female mini jack adapter.

Note: We recommend leaving a distance of approximately 5 cm between lips and microphone to ensure optimal performance.

Controls

  • Press Volume +/Volume - (1) to set the desired volume level.

  • Turn the microphone on/off whenever you want using the On/Off switch (microphone) (2).


Safety

  • Turn the volume down before using the headset, then gradually increase it until achieving the desired volume level.

  • Avoid noisy environments that force you to turn the volume really high when using your headset.

  • Listening to loud music over a long period of time may cause your ears to get used to high volume levels, resulting in irreversible hearing loss.

  • Adjust the volume of your headset to hear important surrounding sounds.


Warranty

Find the full warranty terms and conditions here.


Declaration of conformity

Issuer's name: Energy Sistem Technology, S.A. - CIF: A53107488
Address: C/ Calpe, 1 - 03509 Finestrat - Alicante (Spain)
Tel: + 34 966 830 324

We declare under our own exclusive responsibility that the product

Description: headset
Brand: Energy Sistem
Model: Gaming Headset ESG Metal Core
Manufacturer: Energy Sistem Technology, S.A.
Manufacturing country: China

referred to in this declaration complies with the essential norms and standards:

  • EN 55032:2015+A11:2020
  • EN IEC 61000-3-2:2019
  • EN 61000-3-3:2013/A1:2019
  • EN 55035:2017+A11:2020

in conformity with the essential norms and standards of the Directive 2014/30/EU of the European Parliament and of the Council of 16th April 2014.

Finestrat, 1st September 2022.

Imagen1
Miguel Ángel Aragüez García
Innovation & Technology Director
